SCAME Switch Disconnector 80A 3P+N LINK IP66 (Emergency - Yellow/Red)

The ISOLATORS-AL[EVO] Series switch disconnector is built for emergency applications, with a robust die-cast aluminium enclosure and a yellow/red handle for enhanced visibility at critical isolation points.

Rated at 80A and operating efficiently at 67A under AC23A (415V) conditions, it's configured as 3P+N LINK with an unswitched neutral (solid neutral terminal block) and a Y2 switch size, rated up to 690V. It carries a high IP66 protection rating together with IK10 impact resistance.

The unit features a lockable door interlock and a handle that can be padlocked in the OFF position for up to three padlocks. Cable entry is via an open threaded entry with cap and cable sleeve for a clean, sealed termination.
