SCAME Switch Disconnector 40A 3P+N IP65 (General - Grey/Black, High Wiring Capacity)
Tax included. Shipping calculated at checkout
The SWITCH DISCONNECTOR ISOLATORS-INOX Series is designed for general applications, featuring a durable stainless steel [AISI304L] construction. With a handle of grey/black, this device supports a rated current of 40A and operates efficiently at 35A in AC23A (415V). It is engineered with a high protection degree of IP65 and an impact resistance of IK10, suitable for surface mounting. The switch disconnector is configured with 3P+N poles and includes a late break and early make neutral pole, with a Y1 switch size, operating at a rated voltage of 690V. Notable features include blank sides, a door interlock, and a padlockable handle in the OFF position for up to three padlocks, with increased dimensions for both switch and enclosure.
Eligible for Free Shipping Australia Wide on orders above AU$249
*Excludes Large and Bulky Items
SCAME Switch Disconnector 40A 3P+N IP65 (General - Grey/Black, High Wiring Capacity)
Sale price$1,034.99 AUD
Tech Specs
Product specification
Commerical Series
ISOLATORS-INOX Series
Synthetical Description
SWITCH DISCONNECTOR
Mounting Version
SURFACE MOUNTING
Rated Current
40A
Rated Voltage
690V
Poles
3P+N
Colour
GREY/BLACK
Material
STAINLESS STEEL [AISI304L]
Protection Degree IP
IP65
Protection Degree IK
IK10
Switch Size
Y1
Rated insulation voltage (Ui)
690VAC
Rated impulse voltage (Uimp)
4kV
Thermal current (Ithe)
40A
Current (Ie) in AC21A (415V)
40A
Current (Ie) in AC21A (500V)
32A
Current (Ie) in AC21A (690V)
32A
Current (Ie) in AC22A (415V)
40A
Current (Ie) in AC22A (500V)
32A
Current (Ie) in AC22A (690V)
32A
Current (Ie) in AC23A (415V)
35A
Current (Ie) in AC23A (500V)
25A
Current (Ie) in AC23A (690V)
25A
Current (Ie) in AC3 (415V)
28.5A
Current (Ie) in AC3 (690V)
20A
Current (Ie) in DC22A (250V)
32A
Current (Ie) in DC22A (600V)
10A
Power AC23A (415V)
18.5kW
Short-time current
400A Icw(1s)
Conditional short circuit cur.
10kAeff
Terminals - Flexible wires
1.5-10mm²
Terminals - Rigid wires
1.5-16mm²
