SCAME Switch Disconnector 100A 3P IP66/IP69 (General - Grey/Black, High Wiring Capacity)

The ISOLATORS-TP Series switch disconnector is purpose-built for general industrial and commercial applications requiring reliable load isolation and enhanced operator safety. Constructed from robust engineering plastic, this enclosed surface-mount isolator provides exceptional durability and ingress protection, rated IP66/IP69 and IK09 for impact resistance. This increased-dimension version offers extra wiring capacity for larger cable terminations.

Its high-visibility grey/black handle supports lockout capability in both the OFF (up to three padlocks) and ON (one padlock) positions, ensuring compliance with safety lockout procedures. The unit includes a reversible base and door interlock for added installation flexibility and protection.

Designed for dependable performance, it operates at a rated current of 100A (AC23A at 415V), supports up to 690VAC insulation voltage, and delivers reliable isolation in demanding environments.

Key Features

• Rated Current: 100A (AC23A 415V)
• Poles: 3P
• Enclosure: Engineering plastic, surface mount, increased dimensions
• Protection: IP66/IP69, IK09 impact rating
• Switch Size: Y4
• Handle: Grey/Black, padlockable (OFF 3x / ON 1x padlocks)
• Features: Door interlock, reversible base, increased wiring capacity
